Engine Compartment Overview
Battery
Battery
Brake/Clutch fluid reservoir
Brake fluid reservoir
Engine oil-filler cap
Engine oil-filler cap
MZR 2.0
SKYACTIV-G 2.0
Windscreen washer fluid reservoir
Engine oil dipstick
Engine oil dipstick
Engine coolant reservoir
Engine coolant reservoir
Windscreen washer fluid reservoir
Fuse block
Fuse block
Power steering fluid reservoir
Power steering fluid reservoir
Cooling system cap
Cooling system cap
Automatic transaxle fluid-level dipstick
(Only for automatic transaxle)
