qHeadlight High-Beam Indicator
Light
This light indicates one of two things:
l
The high-beam headlights are on.
l
The direction indicator lever is in the
flash-to-pass position.
qFront Fog Lights Indicator Light
This light illuminates when the front fog
lights are operating.
qRear Fog Light Indicator Light
This light illuminates when the rear fog
light is operating.
q
Low Engine Coolant Temperature
Indicator Light (Blue)
When the ignition is switched ON, the
light illuminates momentarily and then
turns off.
The light illuminates continuously when
the engine coolant temperature is low.
NOTE
If the low engine coolant temperature
indicator light remains illuminated after
the engine has been sufficiently warmed
up, the temperature sensor could have a
malfunction. Consult an expert repairer,
we recommend an Authorised Mazda
Repairer.
qLights-On Indicator Light
This indicator light illuminates when the
exterior lights and instrument panel
illumination are on.
Driving Your Mazda
Warning/Indicator Lights and Beep Sounds
5-47
