Black plate (189,1)
Switch Position
Wiper operation
No.
Type
A
Type
B
Single wipe cycle (mist)
Intermittent
Low speed
High speed
With AUTO position
Switch Position
Wiper operation
No.
Type
A
Type
B
Single wipe cycle (mist)
Auto control
Low speed
High speed
Variable-speed intermittent wipers
Set the lever to the intermittent position
and choose the interval timing by rotating
the ring.
INT ring
AUTO (Auto-wiper control)
When the wiper lever is in the AUTO
position, the rain sensor senses the
amount of rainfall on the windscreen and
turns the wipers on or off automatically
(off―intermittent―low speed―high
speed).
Driving Your Mazda
Switches and Controls
5-59
