3. Stow the two seat belt buckles for the
centre seat in the locations shown the
figure.
4. Store the centre seat seat-bottom.
5. Return the seat-bottom of the second-
row seats to its original position and
secure it. After returning the seat-
bottom to its original position, make
sure the seat-bottom is secured by
attempting to lightly move it up and
down.
Using the seat-bottom
1. Pull the strap and lift the end of the
seat-bottom of the second-row seats.
2. Store the storage box and armrest if
they are in position for use.
Refer to Armrest on page 2-15.
Refer to Storage Box on page 6-70.
3. Pull out the seat-bottom for the centre
seat and set it in its on-road position,
and then pull out the two seat belt
buckles for the centre seat.
4. Return the seat-bottom of the second-
row seats to its original position and
secure it. After returning the seat-
bottom to its original position, make
sure the seat-bottom is secured by
attempting to lightly move it up and
down.
5. Pull out the seat belt tongues an d the
seat belt for the centre seat from the
recess and insert the tongues into the
buckles.
NOTE
When using the centre seat, align the
left and right second-row seats so that
they are positioned in parallel to the
centre seat.
Essential Safety Equipment
Seats
2-11
