qPower/Volume/Sound Controls
Audio control dial Power/Volume dial
The figure is an example showing type A unit.
Power ON/OFF
Switch the ignition to ACC or ON.
Press the power/volum e dial to turn the
audio system on.
Press the power/volum e dial again to turn
the audio system off.
NOTE
To prevent the battery from being
discharged, do not leave the audio
system on for a long period of time
when the engine is not running.
Volume adjustment
To adjust the volume, turn the power/
volume dial.
Turn the power/volum e dial to the right to
increase volume, to the left to decrease it.
Audio sound adjustment
1. Press the audio control dial to select the
function. The selected function will be
indicated.
6-32
Interior Comfort
Audio System
