NOTE
l
When the armrest is in use, the seat
bottom of the centre seat and the
storage box cannot be pulled out or
stored.
l
When the armrest is not in use, it can
be rais ed as shown in the following
figure.
qThird-Row Seat Access
After folding the second-row seat
seatback and sliding the seat forward, you
can access the third-row seat easily.
Entering/exiting the third-row seat area
Raise the lever on the side of the second-
row seat or pull the strap behind the
second-row seat to fold the seatback
forward and slide the seat forward.
After entering/exiting the third-row
seat area
Return the second-row seatback to its
upright position and lock it after sliding it
backward. Make sure it is locked by
attempting to lightly move it forward and
backward.
2-16
Essential Safety Equipment
Seats
