2. Open and fold back the boot board
over the third-row seatback.
Boot board
3. Remove the cargo sub-compartment.
Boot board
Cargo sub-
compartment
4. Turn the tyre hold-down bolt
anticlockwise with the wheel brace.
To secure the spare tyre
Perform the removal procedure in reverse.
7-6
In Case of an Emergency
Flat Tyre
