CAUTION
1 (SKYACTIV-G 2.0)
Being careful not to contact the cowl
grille, insert the tab on the one end of
the battery cover into the holes of the
battery tray and engage the tab.
(MZR 2.0)
Set the battery cover to the battery
tray as shown in the figure while
being careful that it does not contact
the cowl grille.
SKYACTIV-G 2.0
Cowl grille
Tab
Hole
Battery cover Cowl grille
MZR 2.0
CAUTION
2 Attach the clips on both sides of the
battery cover.
Clip
