NOTE
Remove the battery cover before
performing battery maintenance.
CAUTION
l
Do not use a tool which applies
excessive force such as a screwdriver
or pliers.
If excessive force is applied to the
clips, they could be damaged.
To prevent damaging the battery
cover, remove/install the battery
cover using the following procedure.
Removing battery cover
1 Detach the clip facing the side of the
vehicle first and pull it outward with
your finger approx. 4 mm (0.2 in).
Then, lift the cover slightly to clear
the lock.
Clip
8-26
Maintenance and Care
Owner Maintenance
