CAUTION
2 Attach the clips on both sides of the
battery cover.
Clip
CAUTION
l
After installing the battery cover,
make sure that the cover is
completely secured. If it is not
completely secured, it could contact
other systems while the vehicle is
driven causing a malfunction.
Verification location
SKYACTIV-G 2.0
Verification location
MZR 2.0
8-28
Maintenance and Care
Owner Maintenance
Mazda5_8DF6-EI-13J_Edition7 Page324
Thursday, March 9 2017 8:36 PM
Form No.8DF6-EI-13J
