6. Disconnect the bulb from the socket.
Brake lights/Tail lights
Rear direction indicator lights
7. Install the new bulb in the reverse order
of the removal procedure.
NOTE
To inst all the unit, insert the hooks (2
locations) on the unit side into the clips
on the vehicle side, and install the unit.
Clip
Hook
Reverse light, Rear fog light
í
1. Make sure the ignition is switched off,
and the headlight switch is off.
2. Remove the cover with a cloth-
wrapped flathead screwdriver to the
cover.
3. Turn the socket and bulb assembly
anticlockwise and remove it.
Maintenance and Care
Owner Maintenance
8-39
í
Some models.
