Specifications
qEngine
Item
Specification
MZR 2.0 SKYACTIV-G 2.0
Type DOHC-16V in-line, 4-cylinder
Bore × Stroke 87.5 × 83.1 mm (3.44 × 3.27 in) 83.5 × 91.2 mm (3.29 × 3.59 in)
Displacement 1,998 ml (1,998 cc)
Compression ratio 10.0 12.0
qElectrical System
Item
Classification
MZR 2.0 SKYACTIV-G 2.0
Battery 12V-45Ah/20HR or 12V-50Ah/20HR Q-85
*1
Spark-plug number
Mazda
Genuine spark
plug
LFJD-18-110 or
L3Y2-18-110
Mazda
Genuine spark
plug
*2
PE5R-18-110 or
PE5S-18-110
*1 Q-85 is designed for i-stop system (FOR STOP & START) system. Only Q-85 should be used to ensure
correct operation of i-stop system (FOR STOP & START) system. Consult an expert repairer, we recommend
an Authorised Mazda Repairer for details.
*2 The spark plugs provide the SKYACTIV-G its optimum performance. Consult an expert repairer, we
recommend an Authorised Mazda Repairer for details.
CAUTION
When cleaning the iridium plugs, do not use a wire brush. The fine particulate coating on
the iridium alloy and platinum tips could be damaged.
qLubricant Quality
Lubricant type and classification
Engine oil
*1
API SG/SH/SJ/SL/SM/SN or ILSAC GF-II/GF-III/GF-IV/GF-V
*1 Refer to Recommended Oil on page 8-11.
Lubricant Classification
Manual transaxle oil
API Service GL-4
SAE 75W-80
Automatic transaxle fluid
MZR 2.0 Mazda Original Oil ATF M-V
SKYACTIV-G 2.0 Mazda Original Oil ATF-FZ
Power steering fluid ATF M-III, M-V or equivalent (e.g. Dexron® II)
Brake/Clutch fluid SAE J1703 or FMVSS116 DOT-3
10-4
Specifications
