Installing the cover
NOTE
The luggage compartment cover can be
set in two positions depending on the
rear seat recline position or the quantity
of luggag e.
1. Remove the caps with a cloth-wrapped
flathead screwdriver to prevent damage
to the caps.
2. Squeeze the spring ho lders on both
ends of the retractor bar inward.
Spring holders
3. Insert the retractor bar into one of the
two positions.
4. Attach the clips to the head restraint.
Knowing Your Mazda
Doors and Locks
3-25
