McCulloch B26PS User Manual

MAINTENANCE
24 – English
Bevel gear
The bevel gear is filled with the right quantity of grease at
the factory. However, before using the machine you
should check that the bevel gear is filled three-quarters
full with grease. Use HUSQVARNA special grease.
The grease in the bevel gear does not normally need to
be changed except if repairs are carried out.
Checking and adjusting of throttle
wire
Make sure the throttle cable is tight enough without giving
the product gas and cutting equipment starts rotate. The
throttle cable should not be too loose so the product does
not reached full throttle.
Adjust the nut on the throttle cable with the nut. Then
tighten the lock nut.

McCulloch B26PS Specifications

General

Engine Displacement	26 cm³
Power Output	0.75 kW
Cutting Width	43 cm
Weight	5.4 kg
Engine Type	2-stroke
Shaft Type	Straight
Handle Type	Loop
Fuel Tank Volume	0.55 liters
