McCulloch MCC1435A - General Cutting Instructions; 6-1. Felling a Tree

35cc Gas Chain Saw
6/12/2009
No. Parts No. Description Q P Code
1 9SGEB-05-20 SCREW 4 110
2 9SKKB-04-10 SCREW 7 110
3 9067-310802 CAP 1 110
4 9014-310803 GASKET 1 110
5
9292-311001F自
CYLINDER 1 110
6 9067-310801 CAP 1 110
7 9014-310801 GASKET 1 110
8 9189-311001 PISTON RING 2 110
9 9290-311002 PISTON 1 110
10 9CA-10.3 RING 1 110
11 9131-310801 WASHER 1 110
12 9NR-K101411 ROLLER 1 110
13 9PC-10-32 PIN, PISTON 1 110
14 9157-332101 SEAL 1 110
15
9228-310819自
CLY CASE ASS'Y 1 110
15-1 9072-310802F CLY CASE, LEFT 1 110
15-2 9PA-03-08S PIN 3 110
15-3 9072-310801F CLY CASE, RIGHT 1 110
15-4 9SKKB-05-27 SCREW 4 110
16 9DB-620101 BEARING 2 110
MCC1635A
PARTS LIST
17 9228-310801-A CRANK/ROD ASS'Y 1 110
18 9014-310802 GASKET 1 110
19 9CB-32 RING 1 110
20 9157-310801 SEAL 1 110
21 9059-311001 BEARING 1 110
22 9191-310802 SCREW 2 110
23 9010-311002 WIRE 1 110
24 9NCC-05U NUT 2 110
25 9SKKB-05-14 SCREW 2 110
26A AO9014-310810-US888 KIT SPARK ARRESTOR ( 26 & 27) 1 110
26 9014-310810 COVER, MESH 1 110
27 9016-310801 SPARK ARRESTER 1 110
28 9228-311005T MUFFLER ASS'Y 1 110
29 9014-310804 GASKET 1 110
30 9191-310803 SCREW 2 110
31 9010-311003 WIRE 1 110
32 9SKKB-04-14 SCREW 6 110
33 9288-310801 IGNITION ASS'Y 1 110
34 9NHC-08 NUT 1 110
35 9169-310801 FLYWHEEL ASS'Y 1 110
36 6221-830301 WOODRUFF KEY 1 110
37 9014-310805 GASKET 1 110
PARTS LIST
