PARTS IDENTIFICATION/FUNCTIONS
C842 Exploded View (See Figure 1.)
ITEM
PART NO. DESCRIPTION QTY. FUNCTION WARR.
CLASS
1 X72962 Panel A.-Side Upper
Left
1 Provides access to internal com-
ponents for service and cleaning.
103
2 024298 Screw-10-32 X 3/8 6 Secures the panel to the frame. 000
3 072967 Panel-Side Left 1 Provides access to internal com-
ponents for service and cleaning.
103
4 X78330-SER Kit A.-Grease Shield 3 Prevents grease migration. 103
4a 078329 Fastener-Snap in 1/4 x
15/16
24 Fastens the grease shield to the
grill.
000
4b 078285 Shield-Grease 4 Prevents grease migration. 000
5 X72951 Panel A.-Back Service
(Upper)
1 Provides access to internal com-
ponents for service and cleaning.
103
6 X72958-SER
(Includes
6a-6e)
Panel A.-Back Panel
(Lower)
1 Provides access to internal com-
ponents for service and cleaning.
103
6a 072959 Panel-Back 2 Speed
Fan
1 Provides access to internal com-
ponents. Has a two speed fan
connector built into the panel.
103
6b 053889 Cap-Protective Plastic
7/8 THD
1 Protects the plug on the end of
the back panel harness.
000
6c X74158 Harness A.-Back Pnl 1 Connects to the internal harness
in the grill for the 2 speed fan.
103
6d 078327 Nut-Locking Conduit
1/2”
1 Secures the back panel harness
connector to the panel.
000
6e 044823 Connector-Mate Lock 1 Connects the back panel harness
to the internal wire harness.
103
7 X72965 Panel A.-Side Upper
Right
1 Provides access to internal com-
ponents for service and cleaning.
103
8 072968 Panel-Side Right
(Lower)
1 Provides access to internal com-
ponents for service and cleaning.
103
9 078377 Caster-5” 7-5/8 Stem 2 Allows grill mobility. 103
10 073240 Caster-5” Swivel
w/Lock
2 Prevents grill movement. 103
11 X72491-SER Control-Display Inter-
face
3 Controls all functions of the grill. 103
12 076989-WP Switch-Rocker-DPST
10A (Fan Interlock)
1 Activates power to the g rill and
the e xhaust fans.
103
