5
110218
C842 Exploded View
ITEM
PART NO. DESCRIPTION QTY. FUNCTION WARR.
CLASS
13 076012 Button-Operator-Black
(Standby)
3 Activates the cook cycle, keeps
the upper platen in the closed po-
sition, and displays the message
“STANDBY” on the control. When
pressed twice within five
seconds, the upper platen will
automatically lower into the
Standby position.
000
14 076011 Button-Operator-Red
(Raise)
3 Cancels the Standby mode,
raises the upper platen, and de-
activates the Co ok cycle.
000
Figure 1
To Next Page
