McDonald's C842 - C844 Exploded View Parts List

6
110218
C844 Exploded View (See Figure 2.)
ITEM
PART NO. DESCRIPTION QTY. FUNCTION WARR.
CLASS
1 X72786 Panel A.-Side Upper
Left
1 Provides access to internal com-
ponents for service and cleaning.
103
2 024298 Screw-10-32 X 3/8 6 Secures the panel to the frame. 000
3 072790 Panel-Side Left 1 Provides access to internal com-
ponents for service and cleaning.
103
4 X78330-SER Kit A.-Grease Shield 3 Prevents grease migration. 103
4a 078329 Fastener-Snap in 1/4 x
15/16
24 Fastens the grease shield to the
grill.
000
4b 078285 Shield-Grease 4 Prevents grease migration. 000
5 X72951 Panel A.-Back Service
(Upper)
1 Provides access to internal com-
ponents for service and cleaning.
103
6 072959 Panel-Back 2 Speed
Fan
1 Provides access to internal com-
ponents for service and cleaning.
Has a two speed fan connector
built into the panel.
103
7 X72788 Panel A.-Side Upper
Right
1 Provides access to internal com-
ponents for service and cleaning.
103
8 072791 Panel-Side Right
(Lower)
1 Provides access to internal com-
ponents for service and cleaning.
103
9 078377 Caster-5” 7-5/8 Stem 2 Allows grill mobility. 103
10 073240 Caster-5” Swivel
w/Lock
2 Prevents grill movement. 103
11 X72491-SER Control-Display Inter-
face
3 Controls all functions of the grill. 103
12 076989-WP Switch-Rocker-DPST
10A (Fan Interlock)
1 Activates power to the g rill and
the e xhaust fans.
103
13 076012 Button-Operator-Black
(Standby)
3 Activates the cook cycle, keeps
the upper platen in the closed po-
sition, and displays the message
“STANDBY” on the control. When
pressed twice within five
seconds, the upper platen will
automatically lower into the
Standby position.
000
14 076011 Button-Operator-Red
(Raise)
3 Cancels the Standby mode,
raises the upper platen, and de-
activates the Co ok cycle.
000
15 075288 Guard-Lense 3 Protects the Standby button from
being accidentally activated.
103
16 075699SYM3 Label-Control Panel-
International Symbol
1 Set of labels located under the
Raise button (showing platen
raising) and Standby button
(showing platen lowering).
000
