McElroy TracStar 28 - Preparing for Next Fusion Joint

Operation
3 - 10
Position Pipe for Next Joint
Drive the fusion machine to end of pipe, or pull the pipe through
the jaws until the end of the pipe is protruding 1" past the jaw
face of the fixed jaw.
TX00383-9-15-94
PH01906-11-15-00
Install Next Piece of Pipe
Insert a new piece of pipe in movable jaws and repeat all
previous procedures.
TX00384-10-12-95
PH00308-9-24-93
