Maintenance
7 - 9
Checking Track Tension
Park the machine on a flat solid surface.
Use the lifting sling to raise machine off the ground.
Place adequate supports under the the bottom frame after lifting.
Measure the deflection between the bottom center roller and the
inside surface of the rubber track. Track tension is normal when
this distance is about 1/2". If the deflection is more or less than
this, the tension needs to be adjusted.
CD00463-2-25-98
TX01885-11-10-00
Engine Maintenance
Refer to the operation and maintenance manual for the engine.
PH01960-11-15-00
TX01500-3-5-98
