How To Connect
CONNECTING A RECORD PLAYER TO PHONO 1
Connect the cable from the "left" channel of the
record player into the "L" PHONO 1 input jack.
Connect the cable from the "right" channel of the
record player into the "R" PHONO 1 jack.
PHONO 2 is provided for the use of a second record
player.
Connect the cable from the "left" channel of the
record player into the "L" PHONO 2 input jack.
Connect the cable from the "right" channel of the
record player into the "R" PHONO 2 input jack.
CONNECTING A MICROPHONE
Connect the cable from the "left" microphone to
the "L" MIC input jack. Connect the cable from the
"right" microphone to the "R" MIC input jack.
CONNECTING A TAPE DECK FOR PLAYBACK
Connect the cable from the "left" tape recorder head
on the tape deck (one without its own electronics)
to the "L" TAPE HEAD input. Connect the cable
from the "right" tape recorder head to the "R" TAPE
HEAD input.
CONNECTING A STEREO TUNER
Connect the cable from the "left" channel tuner out-
put to the "L" tuner input jack.
Connect the cable from the "right" channel tuner
output to the "R" TUNER jack.
AUX
Any high level program source such as another tuner
or a TV set can be connected to the input jacks
marked "AUX."
CONNECTING A TAPE RECORDER
To Record:
Connect a cable from the "L" TAPE OUTPUT jack
marked TAPE 1 to the "left" high level input tape
recorder.
Connect a cable from the "R" TAPE OUTPUT jack
marked TAPE 1 to the "right" high level input of the
tape recorder.
Connect a second tape recorder in the same fashion
to the TAPE 2 outputs.
To Playback Monitor: Connect the cable from the
"left" channel output of a tape recorder to the high
level inputs . . . "L" TAPE 1.
Connect the cable from the "right" channel output of
a tape recorder to the high level input . . . "R" TAPE.
Connect a second tape recorder in the same fashion
to the TAPE 2 input jacks.
4
