McIntosh C33

FREQUENCY IN HERTZ
-20-
PHONO HARMONIC DISTORTION
AT 2.5 VOLTS OUTPUT
,05
.04
.03
02
.01
0
HARMONIC DISTORTION
IN
PERCENT
20 100
FREQUENCY IN HERTZ
1K
10K 20K
HARMONIC DISTORTION
IN: AUX; OUT: MAIN
2 3 4 5 6 7 8 9 10 11 12
RMS OUTPUT VOLTS
-04
.03
.02
.01
0
HARMONIC DISTORTION
IN
PERCENT
INTERMODULATION DISTORTION
IN: AUX; OUT: MAIN
INPUT FREQUENCY: 60Hz & 7kHz
RATIO: 4:1
.04
.03
.02
.01
0
INTERMODULATION DISTORTION
IN
PERCENT
12
EQUIVALENT OUTPUT VOLTS
MONITOR AMPLIFIER POWER BANDWIDTH
AT .02% T.H.D., 8 OHMS
10 100 1K 10K 100K
32
28
24
20
16
12
8
4
0
POWER OUTPUT
IN
AVERAGE WATTS
FREQUENCY IN HERTZ
MONITOR AMPLIFIER HARMONIC
DISTORTION 20 WATTS OUTPUT
PER CHANNEL, 8 OHMS
.05
.04
.03
.02
.01
0
HARMONIC DISTORTION
IN
PERCENT
20 100 1K 10K 20K
8 9 6 7
4 5 2 3
