FREQUENCY RESPONSE
MONO and STEREO MODES
LEFT, CENTER and RIGHT FRONT channels +0, -0.5dB from 20Hz to 20,000Hz
HALL MODE
LEFT, CENTER and RIGHT FRONT channels, +0, -0.5dB from 20Hz to 20,000Hz.
LEFT and RIGHT SURROUND channels, +0, -3dB from 100Hz to 7000Hz.
DOLBY PRO-LOGIC MODE
LEFT, CENTER and RIGHT FRONT channels, ±0.5dB from 30Hz to 16,000Hz.
LEFT and RIGHT SURROUND channels ±1dB from 100Hz to 6300Hz, -3dB at 7000Hz
DOLBY PRO-LOGIC and THX MODES COMBINED
LEFT, CENTER and RIGHT FRONT channels, ±0.5dB from 30Hz to 1000Hz and ±0.8dB
from 1000Hz to 16,000Hz.
LEFT and RIGHT SURROUND channels, ±1dB from 100Hz to 6300Hz and +1, -5dB to
8000Hz.
ALL MODES
SUBWOOFER channel low pass, 10Hz to a corner frequency of 80Hz with a 24dB per oc-
tave rolloff.
With the rear panel HIGH PASS switch in the ON position, the LEFT, CENTER and RIGHT
FRONT channels include high pass filters with a 12dB per octave rolloff and a corner fre-
quency of 80Hz.
RATED OUTPUT
2.5V at LEFT FRONT, CENTER, RIGHT FRONT, LEFT SURROUND, RIGHT SURROUND
and SUBWOOFER unbalanced.
2.5V at LEFT and RIGHT FRONT Balanced.
OUTPUT IMPEDANCE
600 ohms at all outputs.
MAXIMUM VOLTAGE OUTPUT
6V RMS at all outputs.
TOTAL HARMONIC DISTORTION
MONO, STEREO and HALL MODES
LEFT, CENTER and RIGHT FRONT channels, 0.005% from 20Hz to 20,000Hz.
(HALL MODE, only) LEFT and RIGHT SURROUND channels, 0.01 % from 125Hz to 7000Hz.
DOLBY PRO-LOGIC and THX MODES
LEFT, CENTER and RIGHT FRONT channels, 0.01% from 80Hz to 16,000Hz
LEFT and RIGHT SURROUND channels, 0.1% from 125Hz to 7000Hz.
SENSITIVITY
PHONO: 5.0mV for 2.5V output, (1.0mV IHF).
HIGH LEVEL: 500mV for 2.5V output, (100mV IHF).
DOLBY LEVEL: 200mV input.
29
SPECIFICATIONS
