14
How to Connect the Turntable
How to Connect the Turntable
1. Connect a wire from the MT2 GND (Ground)
Post to the GND (Ground) Post on the McIntosh
Preamplifier, Integrated Amplifier or A/V Control
Center.
2. Connect Audio Cables from the MT2 OUT LEFT
and RIGHT Jacks to the MC (Moving Coil) Inputs
on a McIntosh Preamplifier, Integrated Amplifier
or A/V Control Center.
Notes: 1. The MT2 Turntable with the Blue Point
No. 2 High Output Moving Coil Car-
tridge may also be connected to most
McIntosh Preamplifiers, Integrated
Amplifiers or A/V Control Centers with
a Moving Magnet Phono Input.
2. For additional information about ob-
taining optimum performance from the
installed phono cartridge, refer to page
16 “Phono Cartridge Loading”.
3. Contact your McIntosh Dealer for ad-
ditional information and assistance.
3. Connect the supplied AC / DC Adapter to the MT2
DC IN 12V socket and the Power Supply to a live
AC outlet.
Preamplifier
MT2
AC/ DC
Adapter
To Next Page
