McIntosh MX150

33
Setup Mode, con’t
INSTALLER MENU SUB MENU SELECTION OPTION(S) DESCRIPTION SETUP SHEET NO.
System Setup
Trigger Input Setup
Trigger 1/2, 2/2
Voltage 12V or 5V Sets the required input voltage level to complete
an action
6
Action No action, Zone A Source,
Zone B Source, Zone A (On/
Off), Zone A On, Zone B (On/
Off), Zone B On,
No action when voltage is present; switches
to preselected source for Zone A; switches to
preselected source for Zone B; toggles Zone On
when voltage is present and next time voltage
is present Zone Off; Zone On when voltage is
present and Off when voltage is not present
6
Trigger Output Setup
Trigger 1/4, 2/4
Voltage 12V Sets the required output voltage level to com-
plete an action
6
Duration Level, 5 Seconds, 1 second,
100 ms
Level (constant voltage) or voltage for a speci-
ed time
6
Extra Durartion 0 ms to 2 minutes Additional specied time 6
Action No action, Zone A Source,
Zone B Source, Zone A On,
Zone On, Trigger Input 1,
Trigger Input 2, ACC Power,
Zone A/B On
Take no action; when the preset source for Zone
A is selected; when the preset source for Zone B
is selected; when Zone A is On; when Zone B is
On; when Trigger Input 1 is active; when Trig-
ger Input 2 is active; when the Remote Control
ACC On/Off is used; Zone A or Zone B is On
6
Trigger 3/4, 4/4
Voltage 12V or 5V Sets the required output voltage level to com-
plete an action
6
Duration Level, 5 Seconds, 1 second,
100 ms
Level (constant voltage) or voltage for a speci-
ed time
6
Extra Dutration 0 ms to 2 minutes Additional specied time 6
Action No action, Zone A Source,
Zone B Source, Zone A On,
Zone On, Trigger Input 1,
Trigger Input 2, ACC Power,
Zone A/B On
Take no action; when the preset source for Zone
A is selected; when the preset source for Zone B
is selected; when Zone A is On; when Zone B is
On; when Trigger Input 1 is active; when Trig-
ger Input 2 is active; when the Remote Control
ACC On/Off is used; Zone A or Zone B is On
6
