9
TURN OFF BUTTON: Powers off SmartLOG.
1. Tap TURN OFF button.
2. Tap YES in confirm pop-up window to power off. Wait for button to transition as email/SMS alerts are being sent
out.
Confirm pop-up window “Powering Off In 5 Seconds”.
TROUBLESHOOTING GUIDE
Logger not powering on Check 5v adapter, USB cable, batteries
Not receiving wireless temperatures Check batteries and/or shorten distance between DDL and sensor
Data logger not responding
Remove USB power and batteries: reinstall batteries and connect USB
power cord. Push on button until you hear beep. If no response data logger
may be faulty.
Incorrect Time Turn logger off. Start logger, will update from online time server.
Not able to connect to browser
Name or IP must be entered in the ADDRESS BAR not SEARCH SmartLOG
DDL must be connected to same network as PC or smart phone
Unresponsive web page Click the refresh icon or press the F5 key for PC
Reset to factory
Press RESET button on back of unit until you hear 2 beeps. Unit will reboot.
Will need to re-configure logger.
Email Response: Timed Out
Was not able to connect to your email server, incorrect credentials, email and/
or password.
SPECIFICATIONS
SMARTLOG® DDL MONITOR GATEWAY
Wi-Fi: 802.11 b/g/n (2.4 GHz only)
Security: WPA/WPA2 Enterprise
Display: 240x320 pixel TFT Color Display w/Touch Screen
Screen Update: 60 seconds
Memor: 16MB (2 years of records @ 5 minute intervals)
Ambient Sensor: Temperature range -40 to +125°C (-40°F to 257°F), Humidity range 0-100%RH
Alarms: Audible Piezo Buzzer/Visual LED/SMS/Email
Date/Time: NTP clock synchronization during boot
Power: 5v wall adapter w/5’ micro USB cable
Batteries: Alkaline 1.5v 3 x AA (backup only for power loss)
Battery Life: ~ 3 days with no alarms, (NOTE: replace all batteries after any power loss of more than 1 day)
Working Temp: -20 °C ~ 70 °C
Dimensions: 83 (W) X 120 (H) X 26 (D) mm,
WIRELESS BUFFERED TEMPERATURE SENSOR
Temperature Range: -40C to 50°C (-40°F to 122°F)
Accuracy: ±0.5°C (±1.0°F)
Distance: 50m/164ft (open field), 10m/32ft (inside fridge/freezer)
Buffer medium: Glycol
Batteries: Alkaline 1.5v 2 x AAA
Battery Life: ~1yr
Certification: 2yr NIST ISO17025 Certificate Included
