6 INSTALLATION
6.1 Manual bracket
6.1.1 Siting
The manual bracket should ideally be sited on a bulkhead in plain view near
an emergency exit. When choosing a suitable mounting position you should
also consider:
Ease of access in an emergency, and
Mount at least 1m from any compass equipment.
6.1.2 Mounting procedure
The manual bracket is supplied with four stainless steel screws. The bracket
mounts against a flat surface using 4 fixing points. Offer the bracket into the
chosen position and mark through the mounting slots and drill four 3mm
diameter holes.
