Page 22
6.2.2 Mounting procedure
Mount the back plate on a flat surface using 4 fixing points. Refer to the
illustration for fixing point dimensions or, alternatively, use the back plate of the
enclosure as a marking guide. To do this, push down and turn the cover dial
anti-clockwise then remove the enclosure cover. Note how the EPIRB fits then
remove it to a safe and dry location.
WARNING – The sea contacts are enabled when the EPIRB is removed
from the enclosure.
