Rear Loader
58
Operation
3.5.2 Residential Cart Loading (Optional Cart
Tipper)
1. For pick-up and processing of refuse when equipped
with the optional residential cart tipper.
a. Wheel the residential cart to the back of the cart
tipper.
b. Latch the cart onto the cart tipper (Figure 23, Item 1).
c. Pull the cart tipper dump lever to tip the cart and
dump refuse into the hopper (Figure 23, Item 2).
d. Unlatch and remove the cart.
e. Travel to the next pick-up site.
f. When the hopper area is sufciently lled, perform
the Refuse Packing Procedure as shown in Section
3.6 Refuse Packing Procedure.
Optional Street Side control is available.
12
Figure 23
3.5.3 Commercial Container Loading
WARNING
Be sure all non-operator personnel are clear
of the area around the truck before operating
the Packer. Remain attentive at all times
when operating the controls. Watch the
mirrors for activity. Never back up the
Packer unless and until you are completely
sure it is safe. Use a spotter/observer and/or
get out and check yourself, if necessary, to
ensure it is safe to do so. Thoroughly
understand the controls before operating the
Packer. Failure to heed this warning may
result in serious personal injury or death.
