OUTLINE AND DIMENSIONS
MODEL A B C D E F G H I J K
20A / 20AR
25A / 25AR
30A / 30AR
820 820 363 335 28 930 930 642 622 555 555
40A / 40AR
(32,2) (32,2) (14,3) (13,2) (1,1) (36,6) (36,6) (25,2) (24,5) (21,9) (21,9)
50A / 50AR
Indoor Unit (CKA Series)
• (With Wireless Remote Control & With Wired Remote Control)
All dimensions are in mm / (in)
i
A
B
C
DE
F
H
M
J
I
G
