McQuay A Series - Outdoor Unit (SL - B Series) Dimensions

Outdoor Unit (SL - B Series)
All dimensions are in mm / (in)
Dimension A B C D E F G H J K L M N P Q R
20B / 20BR
840 646 330 297 309 626 41 85 75 177 106 408 378 124 592 78,5
25B / 25BR
(33,1) (25,4) (13,0) (11,7) (12,2) (24,6) (1,6) (3,3) (3,0) (7,0) (4,2) (16,1) (14,9) (4,9) (23,3) (3,1)
30B / 30BR
15 (0,6)
39 (1,5)
840 (33,1)
124 (4,9)
840 (33,1)
297 (11,7)
15 (0,6)
39 (1,5)
5 (0,2)
20 (0,8)
20 (0,8)
2,5 (0,1)
5 (0,2)
160 (6,3)
141
(5,6)
(2,6)
65
20 (0,8)
78,5 (3,1)
124 (4,9)592 (23,3)
378 (14,9)
408 (16,1)
330 (13,0)
330 (13,0)
85
(3,3)
41
(1,6)
(3,0)
75
177 (7,0)
106
(4,2)
626 (24,6)
646 (25,4)
309 (12,2)
