AGR 070A through 100A Product Manual AGR-3
Fouling factor
Performance tables are based on water with a fouling factor of
kWCmorBTUFxhrxft
/0176.0,,/0001.0
22
°×°
per ARI 550/590-98. As fouling increases,
performance decreases. For performance at other than 0.0001 (0.0176) fouling factor see Table 3.
Foreign matter in the chilled water system will adversely affect the heat transfer capability of the
evaporator, and could increase the pressure drop and reduce the water flow. To ensure optimum unit
operation, maintain proper water treatment.
Table 3, Capacity and Power Derates
Fouling Factor
Chilled Water
Delta-T
0.0001 (0.0176) 0.00025 (0.044) 0.00075 (0.132) 0.00175 (0.308)
ALTITUDE
°F °C Cap. Power Cap. Power Cap. Power Cap. Power
6 3.3 0.992 0.995 0.985 0.993 0.962 0.986 0.919 0.972
8 4.4 0.995 0.997 0.988 0.995 0.965 0.988 0.922 0.974
SEA 10 5.6 1.000 1.000 0.993 0.998 0.970 0.991 0.927 0.977
LEVEL 12 6.7 1.005 1.002 0.998 1.000 0.975 0.993 0.932 0.979
14 6.8 1.010 1.005 1.003 1.003 0.980 0.996 0.936 0.982
16 8.9 1.014 1.007 1.007 1.005 0.984 0.998 0.940 0.984
6 3.3 0.978 1.005 0.971 1.003 0.949 0.996 0.906 0.982
8 4.4 0.982 1.007 0.975 1.005 0.953 0.998 0.910 0.984
2000 feet 10 5.6 0.986 1.009 0.979 1.007 0.956 1.000 0.914 0.986
(610 m) 12 6.7 0.992 1.011 0.985 1.009 0.962 1.002 0.919 0.988
14 6.8 0.997 1.014 0.990 1.012 0.967 1.005 0.924 0.991
16 8.9 1.000 1.016 0.993 1.014 0.970 1.007 0.927 0.993
6 3.3 0.966 1.016 0.959 1.014 0.937 1.007 0.895 0.993
8 4.4 0.969 1.018 0.962 1.016 0.940 1.009 0.898 0.995
4000 feet 10 5.6 0.973 1.021 0.966 1.019 0.944 1.012 0.902 0.998
(1220 m) 12 6.7 0.978 1.025 0.971 1.023 0.949 1.016 0.906 1.002
14 6.8 0.982 1.027 0.975 1.025 0.953 1.018 0.910 1.004
16 8.9 0.986 1.028 0.979 1.026 0.956 1.019 0.914 1.005
6 3.3 0.953 1.025 0.946 1.023 0.924 1.016 0.883 1.002
8 4.4 0.955 1.028 0.948 1.026 0.926 1.019 0.885 1.005
6000 feet 10 5.6 0.959 1.031 0.952 1.029 0.930 1.022 0.889 1.008
(1830 m) 12 6.7 0.963 1.034 0.956 1.032 0.934 1.024 0.893 1.011
14 6.8 0.968 1.036 0.961 1.034 0.939 1.026 0.897 1.013
16 8.9 0.972 1.037 0.965 1.035 0.943 1.027 0.901 1.014
Table 4, Equivalent Feet for Fittings
Line Size inch, OD Copper
Fitting Type
7/8 1 1/8 1 3/8 1 5/8 2 1/8 2 5/8 3 1/8
Elbows
90
°
Standard
2.0 2.6 3.3 4.0 5.0 6.0 7.5
90
°
Long Radius
1.4 1.7 2.3 2.6 3.3 4.1 5.0
90
°
Street
3.2 4.1 5.6 6.3 8.2 10 12
45
°
Standard
0.9 1.3 1.7 2.1 2.6 3.2 4.0
45
°
Street
1.5 2.1 3.0 3.4 4.5 5.2 6.4
180
°
Bend
3.2 4.1 5.6 6.3 8.2 10 12
Tees
Full Size 1.4 1.7 2.3 2.6 3.3 4.1 5.0
Reducing 2.0 2.6 3.3 4.0 5.0 6.0 7.5
Valves
Globe Valve, Open 22 29 38 43 55 69 84
Gate Valve, Open 0.9 1.0 1.5 1.8 2.3 2.8 3.2
Angle Valve, Open 9.0 12 15 18 24 29 35
