AGR 070A through 100A Product Manual AGR-3
Table 16, 60 Hz, Compressor And Condenser Fan Motor Amp Draw
Rated Load Amps Locked Rotor Amps
Compressors Compressors
Across-The-Line Part Winding (1)
AGR
Unit
Size
Volts
No.
1
No.
2
Fan
Motors
(Each)
No. Of
Fan
Motors
Fan
Motors
(Each)
No. 1No. 2No. 1No. 2
208 122 135 7.8 4 30.5 N.A. N.A. 400 463
230 112 127 7.2 4 27.6 N.A. N.A. 340 340
380 65 87 4.1 4 20.0 365 365 N/A N/A
460 60 63 3.6 4 13.8 315 315 195 195
070AS
070AM
575 42 48 3.0 4 11.0 245 245 152 152
208 135 135 7.8 6 30.5 N.A. N.A. 463 463
230 127 127 7.2 6 27.6 N.A. N.A. 340 340
380 87 87 4.1 6 20.0 365 365 N/A N/A
460 63 63 3.6 6 13.8 315 315 195 195
075AS
075AM
575 48 48 3.0 6 11.0 245 245 152 152
208 135 162 7.8 6 30.5 N.A. N.A. 463 654
230 127 162 7.2 6 27.6 N.A. N.A. 340 654
380 87 103 4.1 6 20.0 365 740 N/A N/A
460 63 82 3.6 6 13.8 315 510 195 330
080AS
080AM
575 48 68 3.0 6 11.0 245 405 152 262
208 162 162 7.8 6 30.5 N.A. N.A. 654 654
230 162 162 7.2 6 27.6 N.A. N.A. 654 654
380 103 103 4.1 6 20.0 740 740 N/A N/A
460 82 82 3.6 6 13.8 510 510 330 330
085AS
085AM
575 68 68 3.0 6 11.0 405 405 262 262
208 162 162 7.8 6 30.5 N.A. N.A. 654 654
230 162 162 7.2 6 27.6 N.A. N.A. 654 654
380 103 103 4.1 6 20.0 740 740 N/A N/A
460 82 82 3.6 6 13.8 510 510 330 330
090AS
090AM
575 68 68 3.0 6 11.0 405 405 262 262
208 162 202 7.8 6 30.5 N.A. N.A. 654 654
230 162 202 7.2 6 27.6 N.A. N.A. 654 654
380 103 113 4.1 6 20.0 740 740 N/A N/A
460 82 93 3.6 6 13.8 510 510 330 330
095AS
095AM
575 68 72 3.0 6 11.0 405 405 262 262
208 202 202 7.8 6 30.5 N.A. N.A. 654 654
230 202 202 7.2 6 27.6 N.A. N.A. 654 654
380 113 113 4.1 6 20.0 740 740 N/A N/A
460 93 93 3.6 6 13.8 510 510 330 330
100AS
100AM
575 72 72 3.0 6 11.0 405 405 262 262
Notes:
1. Part winding start is a special option on 380 – 575 volt units.
2. All Electrical Data notes are on page 26.
