Product Manual AGR-3 AGR 070A through 100A
31
AGR-AM, Remote Evaporator
Table 20, AGR 070AM - 085AM
PHYSICAL DATA AGR MODEL NUMBER
STANDARD EFFICIENCY 070AM 075AM 080AM 085AM
OUTDOOR UNIT BASIC DATA Ckt.1 Ckt.2 Ckt.1 Ckt.2 Ckt.1 Ckt.2 Ckt.1 Ckt.2
Number Of Refrigerant Circuits 2222
Unit Operating Charge, R-22, lbs. (kg) 60 (27.2) 84 (38.1) 84 (38.1) 86 (39.9) 86 (39.9) 86 (39.9) 86 (39.9) 86 (39.9)
Unit Operating Charge, R-134a, , lbs. (kg) 63 (28.6) 88 (40.0) 88 (40.0) 90 (41.9) 90 (41.9) 90 (41.9) 90 (41.9) 90 (41.9)
Cabinet Dimensions, LxWxH, In. 94.0 x 88.2 x 96.2 136.4 x 88.2 x 96.2 136.4 x 88.2 x 96.2 136.4 x 88.2 x 96.2
Cabinet Dimensions, LxWxH, (mm) 2388 x 2241 x 2444 3463 x 2241 x 2444 3463 x 2241 x 2444 3463 x 2241 x 2444
Unit Operating Weight, Lbs. (kg) 3978 (1802) 4509 (2043) 4743 (2149) 4924 (2331)
Unit Shipping Weight, Lbs. (kg) 3855 (1746) 4384 (1986) 4618 (2092) 4799 (2174)
Add'l Weight If Copper Finned Coils, Lbs. (kg) 830 (375) 1245 (565) 1245 (565) 1245 (565)
COMPRESSORS
Type Semi-Hermetic Semi-Hermetic Semi-Hermetic Semi-Hermetic
Nominal Horsepower 35 40 40 40 40 50 50 50
Number Of Cylinders Per Compressor 66666888
Oil Charge Per Compressor, oz. 140 255 255 255 255 255 255 255
Oil Charge Per Compressor, (g) (3969) (7229) (7229) (7229) (7229) (7229) (7229) (7229)
CAPACITY REDUCTION STEPS - PERCENT OF COMPRESSOR DISPLACEMENT
Standard Staging - Circuit #1 in Lead 0-16-33-49-67 0-17-33-50-67 0-15-42-58-73 0-25-50-63-75
-83-100 -83-100 -86-100 -88-100
Standard Staging - Circuit #2 in Lead 0-17-33-51-67 0-17-33-50-67 0-27-42-56-71 0-25-50-63-75
-84-100 -83-100 -85-100 -88-100
CONDENSERS - HIGH EFFICIENCY FIN AND TUBE TYPE WITH INTEGRAL SUBCOOLING
Coil Face Area,Sq. Ft. 5858878787878787
Coil Face Area, (m
2
) (5.4) (5.4) (8.1) (8.1) (8.1) (8.1) (8.1) (8.1)
Finned Height x Finned Length, In. 100x 83.5 100x 83.5 100x125.3 100x125.3 100x125.3 100x125.3 100x125.3 100x125.3
Finned Height x Finned Length, (mm)
2032 x
2121
2032 x
2121
2540 x
3183
2540 x
3183
2540 x
3183
2540 x
3183
2540 x
3183
2540 x
3183
Fins Per Inch x Rows Deep 16 x 3 16 x 3 16 x 3 16 x 3 16 x 3 16 x 3 16 x 3 16 x 3
Pumpdown capacity @ 90% Lbs. (kg) 108 (49) 108 (49) 162 (73) 162 (73) 162 (73) 162 (73) 162 (73) 162 (73)
Maximum Relief Valve Pressure Setting, psig (kPa) 450 (3103) 450 (3103) 450 (3103) 450 (3103) 450 (3103) 450 (3103) 450 (3103) 450 (3103)
CONDENSER FANS - DIRECT DRIVE PROPELLER TYPE
Number Of Fans - Fan Diameter, In. (mm) 4 - 28 (712) 6 - 28 (712) 6 - 28 (712) 6 - 28 (712)
Number Of Motors - HP (kW) 4 - 2.0 (1.5) 6 - 2.0 (1.5) 6 - 2.0 (1.5) 6 - 2.0 (1.5)
Fan And Motor RPM, 60Hz 1140 1140 1140 1140
60 Hz Fan Tip Speed, FPM (M/Sec) 8357 (35.4) 8357 (35.4) 8357 (35.4) 8357 (35.4)
60 Hz Total Unit Airflow, CFM (M3/sec) 40800 (19.3) 61200 (28.9) 61200 (28.9) 61200 (28.9)
REMOTE DIRECT EXPANSION EVAPORATOR - BAFFLED SHELL AND -TUBE
Model Number, CDE 1204-1 1255-1 1255-1 1255-1
Operating Weight Lbs (kg) 777 (352) 997 (452) 997 (452) 997 (452)
Shipping Weight Lbs (kg) 745 (338) 925 (420) 925 (420) 925 (420)
Diameter, in. - Length, Ft. 12.75- 04 12.75 - 5.5 12.75 - 5.5 12.75 - 5.5
Diameter, (mm) - Length, (mm) 324 - 1220 324 - 1676 324 - 1676 324 - 1676
Water Volume, Gallons, (L) 12.8 (48.5) 17.6 (66.6) 17.6 (66.6) 17.6 (66.6)
Refrigerant Volume, cu. Ft. (cu. m.) 1.25 (.0353) 1.69 (.0478) 1.69 (.0478) 1.69 (.0478)
Operating Charge, Per System, Lbs (kg) (Note 1) 2.8 (1.27) 3.8 (1.72) 3.8 (1.72) 3.8 (1.72)
Water Side Design Pressure, psig (kPa) 225 (1552) 225 (1552) 225 (1552) 225 (1552)
Refrigerant Design Pressure, psig (kPa) 225 (1552) 225 (1552) 225 (1552) 225 (1552)
Water Inlet / Outlet Victaulic Connections, In. (mm) 5 (141.3) 5 (141.3) 5 (141.3) 5 (141.3)
Drain - NPT int, In. (mm) .375 (9.5) .375 (9.5) .375 (9.5) .375 (9.5)
Vent - NPT int, In. (mm) .375 (9.5) .375 (9.5) .375 (9.5) .375 (9.5)
NOTES:
1. Includes evaporator. Does not include suction and liquid line charge. Outdoor unit and evaporator are shipped with R-22 holding charge.
