McQuay AGR 100AS - Table 12, 60 Hz Single Point Power, Field Wiring Data

IOMM AGR AGR 055A through 100A 19
Table 12, 60 Hz Single Point Power, Field Wiring Data
Wiring to Standard Wiring to Optional
AGR Power Block Non-Fused Disconnect Switch
Unit Volts Terminal Connector Wire Range Terminal Connector Wire Range
Size Amps (Copper Wire Only) Amps (Copper Wire Only)
208 335 # 4 - 400 MCM 250 250-500 MCM
230 335 # 4 - 400 MCM 250 250-500 MCM
055A 380 335 # 4 - 400 MCM 150 #2 - 3/0
460 335 # 4 - 400 MCM 150 #2 - 3/0
575 335 # 4 - 400 MCM 100 #6 - 1/0
208 335 # 4 - 400 MCM 400 250 - 500 MCM
230 335 # 4 - 400 MCM 400 250 - 500 MCM
060A 380 335 # 4 - 400 MCM 250 #4 - 350 MCM
460 335 # 4 - 400 MCM 150 #2 - 3/0
575 335 # 4 - 400 MCM 150 #2 - 3/0
208 335 # 4 - 400 MCM 400 250 - 500 MCM
230 335 # 4 - 400 MCM 400 250 - 500 MCM
065A 380 335 # 4 - 400 MCM 250 #4 - 350 MCM
460 335 # 4 - 400 MCM 250 #4 - 350 MCM
575 335 # 4 - 400 MCM 150 #2 - 3/0
208 335 # 4 - 400 MCM 400 250 - 500 MCM
230 335 # 4 - 400 MCM 400 250 - 500 MCM
070A 380 335 # 4 - 400 MCM 250 #4 - 350 MCM
460 335 # 4 - 400 MCM 250 #4 - 350 MCM
575 335 # 4 - 400 MCM 150 #2 - 3/0
208 335 # 4 - 400 MCM 400 250 - 500 MCM
230 335 # 4 - 400 MCM 400 250 - 500 MCM
075A 380 335 # 4 - 400 MCM 250 #4 - 350 MCM
460 335 # 4 - 400 MCM 250 #4 - 350 MCM
575 335 # 4 - 400 MCM 150 #2 - 3/0
208 840 (2 qty.) 1/0 - 600 MCM 400 250 - 500 MCM
230 840 (2 qty.) 1/0 - 600 MCM 400 250 - 500 MCM
080A 380 335 # 4 - 400 MCM 250 #4 - 350 MCM
460 335 # 4 - 400 MCM 250 #4 - 350 MCM
575 335 # 4 - 400 MCM 250 #4 - 350 MCM
208 840 (2 qty.) 1/0 - 600 MCM N/A N/A
230 840 (2 qty.) 1/0 - 600 MCM N/A N/A
085A 380 335 # 4 - 400 MCM 400 250 - 500 MCM
460 335 # 4 - 400 MCM 250 #4 - 350 MCM
575 335 # 4 - 400 MCM 250 #4 - 350 MCM
208 840 (2 qty.) 1/0 - 600 MCM N/A N/A
230 840 (2 qty.) 1/0 - 600 MCM N/A N/A
090A 380 335 # 4 - 400 MCM 400 250 - 500 MCM
460 335 # 4 - 400 MCM 250 #4 - 350 MCM
575 335 # 4 - 400 MCM 250 #4 - 350 MCM
208 840 (2 qty.) 1/0 - 600 MCM N/A N/A
230 840 (2 qty.) 1/0 - 600 MCM N/A N/A
095A 380 335 # 4 - 400 MCM 400 250 - 500 MCM
460 335 # 4 - 400 MCM 250 #4 - 350 MCM
575 335 # 4 - 400 MCM 250 #4 - 350 MCM
208 840 (2 qty.) 1/0 - 600 MCM N/A N/A
230 840 (2 qty.) 1/0 - 600 MCM N/A N/A
100A 380 335 # 4 - 400 MCM 400 250 - 500 MCM
460 335 # 4 - 400 MCM 250 #4 - 350 MCM
575 335 # 4 - 400 MCM 250 #4 - 350 MCM
All Electrical Data notes are on page 20
