14 IMM AGS-2
Table 1, Dimensions
MODEL A B C CC D E EE F G
120 36.00 136.60 12.00 21.00 57.30 174.60 165.60 71.49 186.60
125 36.00 168.85 12.00 21.00 69.25 212.80 203.80 86.54 224.80
130 36.00 136.60 12.00 21.00 57.30 174.60 165.60 71.49 186.60
135 36.00 168.85 12.00 21.00 69.25 212.80 203.80 86.54 224.80
140 36.00 136.60 12.00 21.00 57.30 174.60 165.80 71.49 186.60
145 36.00 168.85 12.00 21.00 69.25 212.80 203.80 86.66 224.80
160 36.00 136.60 12.00 21.00 57.30 174.60 165.60 74.37 186.60
165 36.00 189.00 12.00 21.00 84.00 251.00 242.00 105.17 263.00
170 36.00 168.85 12.00 21.00 69.25 212.80 203.80 89.65 224.80
175 36.00 189.00 12.00 21.00 84.00 251.00 242.00 105.17 263.00
180 36.00 168.85 12.00 21.00 69.25 212.80 203.80 89.65 224.80
190 36.00 168.85 12.00 21.00 69.25 212.80 203.80 89.65 224.80
195 36.00 189.00 12.00 21.00 84.00 251.00 242.00 105.17 263.00
210 36.00 189.00 12.00 21.00 84.00 251.00 242.00 105.17 263.00
NOTES:
1. Use location “C”, not “CC”, for mounting.
2. Center of gravity (F) is calculated from shipping weight
3. Dimensions are in inches.
4. Mounting holes are 0.75 inch diameter and have center located 2.0 inches from the outside edge.
Table 2, Lifting and Mounting Weights, Packaged, Aluminum Fins, AGS-CS/H
Lifting Weights Mounting Weights
L1, L2 L3, L4 MM1, MM2 M3, M4 MM5, MM6
Operating
Weight
Shipping
Weight
AGS
lbs kg lbs kg lbs kg lbs kg lbs kg lbs kg lbs kg
120 2919 1324 1591 722 1749 793 1645 746 1333 605 9452 4287 9020 4091
125 3161 1434 1941 880 1996 905 1887 856 1583 718 10930 4958 10205 4629
130 2919 1324 1591 722 1749 793 1645 746 1333 605 9452 4287 9020 4091
135 3161 1434 1941 880 1996 905 1887 856 1583 718 10930 4958 10205 4629
140 2919 1324 1591 722 1749 793 1645 746 1333 605 9452 4287 9020 4091
145 3075 1395 1896 860 1916 869 1810 821 1517 688 10485 4756 9942 4510
160 2933 1330 1809 821 1802 817 1742 790 1561 708 10209 4631 9484 4302
165 3017 1369 2489 1129 2137 969 2038 924 1789 811 11928 5411 11011 4995
170 3269 1483 2007 910 1945 882 1904 864 1790 812 11277 5115 10552 4786
175 3017 1369 2489 1129 2137 969 2038 924 1789 811 11928 5411 11011 4995
180 3269 1483 2007 910 1945 882 1904 864 1790 812 11277 5115 10552 4786
190 3269 1483 2007 910 1945 882 1904 864 1790 812 11277 5115 10552 4786
195 3017 1369 2489 1129 2137 969 2038 924 1789 811 11928 5411 11011 4995
210 3017 1369 2489 1129 2137 969 2038 924 1789 811 11928 5411 11011 4995
Table 3, Lifting and Mounting Weights, Packaged Copper Fins, AGS-CS/H
Lifting Weights Mounting Weights
L1, L2 L3, L4 MM1, MM2 M3, M4 MM5, MM6
Operating
Weight
Shipping
Weight
AGS
lbs kg lbs kg lbs kg lbs kg lbs kg lbs kg lbs kg
120
3557 1613 2229 1011 2174 986 2070 939 1758 798 10728 4866 10296 4670
125
3959 1796 2739 1242 2528 1147 2419 1097 2115 959 12526 5682 11801 5353
130
3557 1613 2229 1011 2174 986 2070 939 1758 798 10728 4866 10296 4670
135
3959 1796 2739 1242 2528 1147 2419 1097 2115 959 12526 5682 11801 5353
140
3557 1613 2229 1011 2174 986 2070 939 1758 798 10728 4866 10296 4670
145
3873 1757 2694 1222 2448 1110 2342 1062 2049 929 12081 5480 11538 5234
160
3571 1620 2447 1110 2227 1010 2167 983 1986 901 11485 5210 10760 4881
165
3975 1803 3447 1564 2776 1259 2677 1214 2428 1101 13844 6280 12927 5864
170
4067 1845 2805 1272 2477 1124 2436 1105 2322 1053 12873 5839 12148 5510
175
3975 1803 3447 1564 2776 1259 2677 1214 2428 1101 13844 6280 12927 5864
180
4067 1845 2805 1272 2477 1124 2436 1105 2322 1053 12873 5839 12148 5510
190
4067 1845 2805 1272 2477 1124 2436 1105 2322 1053 12873 5839 12148 5510
195
3975 1803 3447 1564 2776 1259 2677 1214 2428 1101 13844 6280 12927 5864
210
3975 1803 3447 1564 2776 1259 2677 1214 2428 1101 13844 6280 12927 5864
