70
IMM AGS-2
Component Location
Major Component Location
Figure 38, Unit Cutaway View
Control Panel
Power Panel
Two-circuit DX Evaporator
Filter-drier (2)
Electronic
Expansion
Valve (2)
Suction Connection for
Remote Evaporators (2)
Liquid Connection for Remote
Evaporators, Models AGS 120C – 175C
Chilled Water Inlet
Chilled Water Outlet
