McQuay AGS 210CS/H User Manual

26 IMM AGS-2
Physical Data, Standard Efficiency
Table 16, Physical Data, AGS 120C – AGS 140C
AGS MODEL NUMBER
120C 130C 140C
DATA
Ckt 1 Ckt 2 Ckt 1 Ckt 2 Ckt 1 Ckt 2
BASIC DATA
Unit Cap. @ 44°F LWT, 95°F Ambient
Temperature kW, (tons)
116.7 (410) 125.2 (440) 133.7 (470)
Unit Operating Charge lbs (kg) 131 (59) 131 (59) 131 (59) 131 (59) 131 (59) 131 (59)
Cabinet Dimensions
L x W x H, in. (mm)
187 x 89 x 101
4750 x 2261 x 2565
187 x 89 x 101
4750 x 2261 x 2565
187 x 89 x 101
4750 x 2261 x 2565
Unit Operating Weight, lbs. (kg) 9452 (4291) 9452 (4291) 9452 (4291)
Unit Shipping Weight, lbs (kg) 9020 (4095) 9020 (4095) 9020 (4095)
Economizer No No No
COMPRESSORS, SCREW, SEMI-HERMETIC
Nominal Capacity, tons (kW) 60 (211) 60 (211) 60 (211) 70 (246) 70 (246) 70 (246)
CONDENSERS, HIGH EFFICIENCY FIN AND TUBE TYPE WITH INTEGRAL SUBCOOLER
Pumpdown Capacity, lbs (kg) 358 (163) 358 (163) 358 (163) 358 (163) 358 (163) 358 (163)
CONDENSER FANS, DIRECT DRIVE PROPELLER TYPE
No. of Fans – 30 in. Fan Dia. 8 8 8
No. of Motors -- hp (kW) 8 2 (1.5) 8 2 (1.5) 8 2 (1.5)
Fan & Motor RPM, 60Hz 1140 1140 1140
60 Hz Fan Tip Speed, fpm (m/s) 8950 (4224) 8950 (4224) 8950 (4224)
60 Hz Total Unit Airflow, cfm (l/s) 86900 (41020) 86900 (41020) 86900 (41020)
EVAPORATOR, DIRECT EXPANSION SHELL AND TUBE
Shell Dia.-Tube Length
in.(mm) - in. (mm)
15.5 x 82.4
(394 x 2093)
15.5 x 82.4
(394 x 2093)
15.5 x 82.4
(394 x 2093)
Evaporator R-134a Charge lbs (kg) 1.95 (0.9) 1.95 (0.9) 1.95 (0.9) 1.95 (0.9) 1.95 (0.9) 1.95 (0.9)
Water Volume, gallons (liters) 49 (185) 49 (185) 49 (185)
Max. Water Pressure, psi (kPa) 152 (1048) 152 (1048) 152 (1048)
Max. Refrigerant Press., psi (kPa) 352 (2427) 352 (2427) 352 (2427)
Table 17, Physical Data, AGS 160C – AGS 180C
AGS MODEL NUMBER
DATA 160C 170C 180C
Ckt. 1 Ckt. 2 Ckt. 1 Ckt. 2 Ckt. 1 Ckt. 2
BASIC DATA
Unit Cap. @ 44°F LWT, 95°F Ambient
Temperature kW, (tons)
151.4 (532) 168.1 (591) 179.6 (631)
Unit Operating Charge, lbs (kg) 131 (59) 131 (59) 159 (72) 159 (72) 171 (78) 171 (78)
Cabinet Dim., L x W x H, in. (mm)
187 x 89 x 101
4750 x 2261 x 2565
225 x 89 x 101
5715 x 2261 x 2565
225 x 89 x 101
5715 x 2261 x 2565
Unit Operating Weight, lbs. (kg) 10209 (4635) 11277 (5120) 11277 (5120)
Unit Shipping Weight, lbs (kg) 9484 (4306) 10552 (4791) 10552 (4791)
Economizer No No Yes
COMPRESSORS, SCREW, SEMI-HERMETIC
Nominal Capacity, tons (kW) 70 (246) 85 (299) 85 (299) 85 (299) 95 (334) 95 (334)
CONDENSERS, HIGH EFFICIENCY FIN AND TUBE TYPE WITH INTEGRAL SUBCOOLER
Pumpdown Capacity, lbs (kg) 358 (163) 358 (163) 399 (181) 399 (181) 399 (181) 399 (181)
CONDENSER FANS, DIRECT DRIVE PROPELLER TYPE
No. of Fans; 30 in. Fan Dia., 8 10 10
No. of Motors – hp (kW) 8 2 (1.5) 10 2 (1.5) 10 2 (1.5)
Fan & Motor RPM, 60Hz 1140 1140 1140
60 Hz Fan Tip Speed, fpm 8950 (4224) 8950 (4224) 8950 (4224)
60 Hz Total Unit Airflow, cfm (l/s) 86900 (41020) 108630 (51280) 108630 (51280)
EVAPORATOR, DIRECT EXPANSION SHELL AND TUBE
Shell Dia.,Tube Length in.(mm)
19.4 x 82.4
(493 x 2093)
19.4 x 105.1
(493 x 2670)
19.4 x 105.1
(493 x 2670)
Evaporator R-134a Charge lbs (kg) 2.53 (1.1) 2.53 (1.1) 3.16 (1.4) 3.16 (1.4) 3.16 (1.4) 3.16 (1.4)
Water Volume, gallons (liters) 83 (314) 106 (401) 106 (401)
Max. Water Pressure, psi (kPa) 152 (1048) 152 (1048) 152 (1048)
Max. Refrigerant Press., psi (kPa) 352 (2427) 352 (2427) 352 (2427)
