IMM AGS-2
69
Solid State Starter Settings
Operating Parameters Settings for Default Value and Settable Range:
Table 43, Starter Settings
No. Operating Parameter Default Range of Setting
P1
Motor Full Load Amps (FLA) 1A 1 to 9999A
P2
Motor Rated Load Amps (RLA) 1A 1 to 9999A
P3
Motor Service Factor 1.25 1-1.99
P4
Motor Overload Class 10 1-40,Off
P5
Initial Motor Starting Current 225% 50 - 400%
P6
Max. Motor Starting Current 300% 100 – 800%
P7
Motor Ramp Time 7 sec 0 - 300 sec
P8
UTS time 10 sec 1 - 900 sec
P9
Stop Mode Cos Coast/Voltage decel
P10
Deceleration Level 1 40% 0 – 100%
P11
Deceleration Level 2 20% 0 – 50%
P12
Deceleration Time 2 sec 1 – 180 sec
P13
Default Meter Display 0(Status) 0-19
P14
Overcurrent Trip Level 140% Off, 50 to 800%RLA
P15
Overcurrent Trip Time 2 sec Off, .1 – 90 sec
P16 Rated RMS Voltage 460
100,110,120,200,208,220,230,24
0,350,380,400,415,440,460,480,
500,525,575,600,660,690,1000
P17
Overvoltage Trip Level 10% Off, 1 – 40% rated volts
P18
Undervoltage Trip Level 10% Off, 1 – 40% rated volts
P19
Over/Under Voltage Delay Time 1 Sec .1-90 Sec
P20
Current Imbalance Trip Level 40% 5 - 40%
P21
Controlled Fault Stop Off Off, On
P22
Auto Fault Reset Delay Time 60 Off, 1 – 120 sec
P23
CT Ratio 2640
72,96,144,288,864,2640,2880,57
60,8000,14400,28800
P24
Control Source Ter Terminal/Network
P25
Modbus Address 2 1 - 247
P26
Modbus Baud Rate 19.2 Kbps 1.2,2.4,4.8,9.6,19.2 kbps
P27
Modbus Timeout 1 sec Off, 1 – 120 sec
P28
Analog Output Function 1 1 - 11
P29
Analog Output Span 100% 1 – 125%
P30
Analog Output Offset 0% 0 – 99%
P31
Passcode 0-9999
P32
Fault Log Display faults
