1-2
! Warning
• Installation and maintenance should be performed by qualified persons who are familiar with local code and
regulation, and experienced with this type of appliance.
• All field wiring must be installed in accordance with the national wiring regulation.
• Ensure that the rated voltage of the unit corresponds to that of the name plate before commencing wiring work
according to the wiring diagram.
• The unit must be GROUNDED to prevent possible hazard due to insulation failure.
• All electrical wiring must not touch the water piping and any moving parts of the fan motors.
• Confirm that the unit has been switched OFF before installing or servicing the unit.
IMPORTANT
DO NOT INSTALL OR USE THE AIR CONDITIONER UNIT IN A LAUNDRY ROOM.
Before installing the air conditioner unit, please read the following safety precautions carefully.
SAFETY PRECAUTIONS
CONTENTS
! Caution
Please take note on the following important points when installing.
• Ensure that the drainage piping is connected properly.
If the drainage piping is not connected properly, it may cause water leakage which will dampen the
furniture.
• Ensure that the unit panel is covered back after service or installation.
Unsecured panel will cause unit to operate noisily.
- Outline and Dimensions page i-ii
- Safety Precautions page 2
- Installation Diagram page 3
- Installation of The Indoor Unit page 3
- Electrical Connection page 3
- Water Piping Connection page 4
- Electrical Wiring Connection page 4
- Overall Checking page 5
- Service and Maintenance page 5
- Trouble Shooting page 6
To Next Page
