Electrical and Wiring
x Refer to the wiring diagram provided on the unit when making electrical wiring.
x Install an isolator (if it is not provided) to prevent electrical shock.
x Do not ground any electrical equipment to the water piping.
x Operation of the mini chiller without any fan speed controller (Field supply) is limited to an ambient
temperature of 20ºC. With the fan speed controller (Field supply), the unit is able to operate down to -
5ºC.
Cooling Only Unit
Model
M4AC080C
MAC080C
M4AC100C
MAC100C
M4AC120C
MAC120C
M4AC150C
MAC150C
Voltage Range **
380
-
415V /3Ph /50Hz
+
N
+
Recommended Fuse * A 35 40 50 60
Power Supply Cable Size * mm
2
Number of Conductor
10
5
10
5
Interconnection Cable Size * mm
2
1.5 1.5
Heat Pump Unit
Model
M4AC080CR
MAC080CR
M4AC100CR
MAC100CR
M4AC120CR
MAC120CR
M4AC150CR
MAC150CR
Voltage Range **
380
-
415V /3Ph /50Hz
+
N
+
Recommended Fuse * A 35 40 50 60
Power Supply Cable Size * mm
2
Number of Conductor
10
5
10
5
Interconnection Cable Size * mm
2
1.5 1.5
IMPORTANT : * The figures shown in the table are for information purpose only. They should be checked
and selected to comply with the local/national codes of regulations. This is also subject
to the type of installation and conductors used.
** The appropriate voltage range should be checked with label data on the unit.
