Cooling Only (MAC080C/100C/120C/150C)
Ref r i ger ant Fl ow Di r ect i on
4、BPHE
1、Compr essor
2、Heat Exchanger Fan
5、Wat er Pump
3、Cool i ng Cap. Tube
6、Wat er Fl ow Swi t ch
Chilled Wat er I n
Chilled Wat er Out
LEGEND
