McQuay MAC 100 CR Installation And Maintenance

Heat Pump (MAC080CR/100CR/120CR/150CR)
Ref r i ger ant Fl ow Di r ect i on When Heat i ng
7、Heat i ng Cap. Tube
11、Wat er Pump
3、Accumul at or
Ref r i ger ant Fl ow Di r ect i on When Cool i ng
1、Compr essor
9、Recei ver
LEGEND
2、Four Way Val ve
6、Cool i ng Cap. Tube
10、BPHE
12、Wat er Fl ow Swi t ch
4、Copper Tube Al uminium Fin
Heat Exchanger
8、Check Val ve
Chilled Wat er
In
Chilled Wat er
Out
Page 49

McQuay MAC 100 CR Specifications

General

Brand	McQuay
Model	MAC 100 CR
Category	Chiller
Language	English
