McQuay MAC 100 CR User Manual

6.2.7 Advance Parameter Settings
The Chiller Panel provide user a lot of advance parameter settings for the Chiller. The parameters are divided into 7
groups. There all are stored in [Set Parameter] menu and it is password-protected layer in the panel.
*CAUTION: INPROPER SETTINGS WILL CAUSE PERMANENT DAMAGE TO THE CHILLER!!!
<ENTER> <ENTER>
<ESC> <ESC>
<ENTER> <ESC>
Key in password
7 groups of Advance Parameter:
1) General
2) Sensor
G1 Model : Chiller
G2 No.Comp : 1 Comp
G3 On/Off In : Disabale
G4 Co/ Heat In : Disable
G5 Ext Alarm in : Disable
G6 Water Sys : Isolated
G7 Unit No : 0
Summary Pages Main Menu
Set Parameter
S8 Cp Dish 1 : 0.0ºC
S9 Cp Dish 2 : 0.0ºC
S10 Cp Dish 3 : 0.0ºC
S11 Cp Dish 4 : 0.0ºC
S1 Water Enter : 0.0ºC
S2 Water Leave : 0.0ºC
S3 Air Sensor : 0.0ºC
S4 Defrost 1 : 0.0ºC
S5 Defrost 2 : 0.0ºC
S6 Defrost 3 : 0.0ºC
S7 Defrost 4 : 0.0ºC
Settings Menu
3) Regulator
R1 Cool SP : 12.0ºC
R2 Cool Diff : 3.0ºC
R3 Heat SP : 40.0ºC
R4 Heat Diff : 3.0ºC
R5 Mix Cool SP : -20ºC
R6 Max Cool SP : 40ºC
R7 Min Heat SP : -20ºC
R8 Max Heat SP : 90ºC
R9 Ax Heat SP : 5.0ºC
R10 Ax Heat Diff : 2.0ºC
R11 Au Bo SP : 5.0ºC
R12 Au Bo Diff : 2.0ºC
R13 Au Bo Start : 30m
24
