70
Model: MCC 030 C
1. PANEL TOP ASSY.
2. TERMINAL BOX ASSY.
3. COIL TUBING ASSY.
4. DRAIN PAN SMALL ASSY.
5. DRAIN PAN BIG ASSY.
6. BLOWER ASSY.
7. BLOWER PANEL
8. BLOWER FLANGE
