McQuay MCK 020A User Manual

B Series (Cooling Only – R22)
Model : MCK015B / MLC015B
Indoor DB Indoor WB Capacity Outdoor DB, ° C
° C ° C kW 19.4 25 30 35 40 46
26.7 13.9 TC 3.661 3.438 3.238 3.039 2.840 2.601
SC 3.661 3.438 3.238 3.039 2.840 2.601
15 TC 3.870 3.617 3.390 3.164 2.938 2.666
SC 3.462 3.272 3.103 2.934 2.764 2.561
18 TC 4.441 4.105 3.805 3.505 3.205 2.845
SC 2.920 2.821 2.733 2.645 2.557 2.452
19.4 TC 4.707 4.332 3.998 3.664 3.329 2.928
SC 2.667 2.611 2.561 2.511 2.461 2.401
20 TC 4.821 4.440 4.100 3.761 3.421 3.013
SC 2.559 2.506 2.459 2.412 2.365 2.309
22 TC 5.201 4.800 4.442 4.084 3.726 3.296
SC 2.197 2.156 2.120 2.083 2.047 2.003
24 TC 5.582 5.160 4.784 4.407 4.031 3.579
SC 1.836 1.807 1.781 1.755 1.729 1.697
Model : MCK020B / MLC020B
Indoor DB Indoor WB Capacity Outdoor DB, ° C
° C ° C kW 19.4 25 30 35 40 46 50 52 54
26.7 13.9 TC 5.569 5.229 4.925 4.622 4.183 3.879 3.733 3.676 3.630
SC 5.262 4.986 4.740 4.495 4.068 3.773 3.630 3.575 3.531
15 TC 5.749 5.412 5.112 4.811 4.354 4.038 3.886 3.827 3.779
SC 5.036 4.783 4.557 4.331 3.920 3.636 3.498 3.445 3.402
18 TC 6.241 5.913 5.620 5.328 4.822 4.472 4.303 4.237 4.185
SC 4.422 4.230 4.057 3.885 3.517 3.262 3.138 3.091 3.052
19.4 TC 6.471 6.147 5.858 5.569 5.040 4.674 4.498 4.429 4.374
SC 4.136 3.971 3.824 3.677 3.328 3.087 2.970 2.925 2.889
20 TC 6.569 6.238 5.943 5.648 5.112 4.741 4.562 4.493 4.437
SC 4.013 3.850 3.705 3.560 3.222 2.989 2.875 2.832 2.797
22 TC 6.897 6.544 6.229 5.913 5.352 4.964 4.776 4.703 4.645
SC 3.604 3.448 3.309 3.170 2.869 2.661 2.560 2.521 2.490
24 TC 7.225 6.849 6.514 6.178 5.592 5.186 4.990 4.914 4.853
SC 3.194 3.045 2.912 2.779 2.515 2.333 2.244 2.210 2.183
HIGH AMBIENT
Model : MCK025B / MLC025B
Indoor DB Indoor WB Capacity Outdoor DB, ° C
° C ° C kW 19.4 25 30 35 40 46 50 52 54
26.7 13.9 TC 5.950 5.748 5.569 5.389 5.223 4.958 4.830 4.782 4.743
SC 5.614 5.483 5.367 5.250 5.089 4.830 4.706 4.658 4.620
15 TC 6.682 6.336 6.027 5.718 5.542 5.260 5.125 5.073 5.032
SC 5.487 5.331 5.192 5.053 4.897 4.648 4.529 4.483 4.446
18 TC 8.679 7.938 7.277 6.615 6.412 6.086 5.929 5.869 5.822
SC 5.141 4.916 4.715 4.514 4.375 4.152 4.045 4.005 3.972
19.4 TC 9.611 8.686 7.860 7.034 6.817 6.471 6.305 6.241 6.190
SC 4.979 4.722 4.492 4.262 4.131 3.921 3.820 3.781 3.751
20 TC 10.010 9.047 8.186 7.326 7.100 6.739 6.566 6.500 6.447
SC 4.910 4.643 4.405 4.166 4.038 3.833 3.734 3.697 3.667
22 TC 11.342 10.249 9.274 8.298 8.043 7.634 7.438 7.363 7.303
SC 4.679 4.381 4.114 3.848 3.729 3.540 3.449 3.414 3.386
24 TC 12.673 11.452 10.362 9.271 8.986 8.529 8.310 8.226 8.159
SC 4.449 4.119 3.824 3.529 3.421 3.247 3.163 3.131 3.106
HIGH AMBIENT
30
