B Series (Heating Mode – R22)
Model : MCK015BR/ MLC015BR (HEATING MODE)
Indoor DB°C
Outdoor WB°C kW 15.0 17.0 19.0 21.0 24.0 26.7
-9.0
TC 1.843 1.811 1.779 1.747 1.747 1.746
SC 1.843 1.811 1.779 1.747 1.747 1.746
-5.0
TC 2.211 2.191 2.172 2.152 2.122 2.095
SC 2.211 2.191 2.172 2.152 2.122 2.095
FROST REGION
6.0
TC 3.223 3.321 3.419 3.517 3.273 3.054
SC 3.223 3.321 3.419 3.517 3.273 3.054
12.0
TC 3.774 3.741 3.707 3.673 3.623 3.577
SC 3.774 3.741 3.707 3.673 3.623 3.577
15.0
TC 4.050 4.014 3.978 3.942 3.888 3.839
SC 4.050 4.014 3.978 3.942 3.888 3.839
18.3
TC 4.354 4.315 4.276 4.237 4.179 4.127
###
SC 4.354 4.315 4.276 4.237 4.179 4.127
###
Model : MCK020BR/ MLC020BR (HEATING MODE)
Indoor DB°C
Outdoor WB°C kW 15.0 17.0 19.0 21.0 24.0 26.7
-9.0
TC 3.150 3.105 3.060 3.016 2.999 2.984
SC 3.150 3.105 3.060 3.016 2.999 2.984
-5.0
TC 3.719 3.685 3.652 3.619 3.569 3.524
SC 3.719 3.685 3.652 3.619 3.569 3.524
FROST REGION
6.0
TC 5.284 5.428 5.571 5.715 5.343 5.008
SC 5.284 5.428 5.571 5.715 5.343 5.008
12.0
TC 6.138 6.083 6.028 5.974 5.892 5.818
SC 6.138 6.083 6.028 5.974 5.892 5.818
15.0
TC 6.565 6.506 6.448 6.389 6.301 6.222
SC 6.565 6.506 6.448 6.389 6.301 6.222
18.3
TC 7.034 6.972 6.909 6.846 6.752 6.668
###
SC 7.034 6.972 6.909 6.846 6.752 6.668
###
Model : MCK025BR/ MLC025BR (HEATING MODE)
Indoor DB°C
Outdoor WB°C kW 15.0 17.0 19.0 21.0 24.0 26.7
-9.0
TC 3.648 3.614 3.580 3.546 3.499 3.456
SC 3.648 3.614 3.580 3.546 3.499 3.456
-5.0
TC 4.205 4.167 4.130 4.092 4.035 3.985
SC 4.205 4.167 4.130 4.092 4.035 3.985
FROST REGION
6.0
TC 5.738 6.072 6.407 6.741 6.055 5.438
SC 5.738 6.072 6.407 6.741 6.055 5.438
12.0
TC 6.574 6.515 6.457 6.398 6.310 6.231
SC 6.574 6.515 6.457 6.398 6.310 6.231
15.0
TC 6.992 6.930 6.867 6.805 6.711 6.627
SC 6.992 6.930 6.867 6.805 6.711 6.627
18.3
TC 7.452 7.385 7.319 7.253 7.153 7.063
###
SC 7.452 7.385 7.319 7.253 7.153 7.063
###
