Model : MCK030BR/ MLC030BR (HEATING MODE)
Indoor DB°C
Outdoor WB°C kW 15.0 17.0 19.0 21.0 24.0 26.7
-9.0
TC 4.600 4.562 4.523 4.484 4.418 4.358
SC 4.600 4.562 4.523 4.484 4.418 4.358
-5.0
TC 5.281 5.233 5.186 5.139 5.068 5.004
SC 5.281 5.233 5.186 5.139 5.068 5.004
FROST REGION
6.0
TC 7.152 7.504 7.855 8.206 7.455 6.779
SC 7.152 7.504 7.855 8.206 7.455 6.779
12.0
TC 8.173 8.100 8.027 7.955 7.845 7.747
SC 8.173 8.100 8.027 7.955 7.845 7.747
15.0
TC 8.684 8.606 8.529 8.451 8.335 8.231
SC 8.684 8.606 8.529 8.451 8.335 8.231
18.3
TC 9.245 9.163 9.080 8.998 8.874 8.763
###
SC 9.245 9.163 9.080 8.998 8.874 8.763
###
B Series (Heating Mode – R407C)
Model : MCK015BR/ M4LC015BR (HEATING MODE)
Indoor DB°C
Outdoor WB°C kW 15.0 17.0 19.0 21.0 24.0 26.7
-9.0
TC 1.690 1.660 1.631 1.601 1.601 1.601
SC 1.690 1.660 1.631 1.601 1.601 1.601
-5.0
TC 2.027 2.009 1.991 1.972 1.945 1.921
SC 2.027 2.009 1.991 1.972 1.945 1.921
FROST REGION
6.0
TC 2.954 3.044 3.134 3.224 3.001 2.800
SC 2.954 3.044 3.134 3.224 3.001 2.800
12.0
TC 3.460 3.429 3.398 3.367 3.321 3.279
SC 3.460 3.429 3.398 3.367 3.321 3.279
15.0
TC 3.713 3.680 3.647 3.613 3.564 3.519
SC 3.713 3.680 3.647 3.613 3.564 3.519
18.3
TC 3.991 3.955 3.920 3.884 3.831 3.783
###
SC 3.991 3.955 3.920 3.884 3.831 3.783
###
Model : MCK020BR/ M4LC020BR (HEATING MODE)
Indoor DB°C
Outdoor WB°C kW 15.0 17.0 19.0 21.0 24.0 26.7
-9.0
TC 3.231 3.185 3.139 3.093 3.076 3.061
SC 3.231 3.185 3.139 3.093 3.076 3.061
-5.0
TC 3.814 3.780 3.746 3.712 3.661 3.614
SC 3.814 3.780 3.746 3.712 3.661 3.614
FROST REGION
6.0
TC 5.420 5.567 5.715 5.862 5.480 5.137
SC 5.420 5.567 5.715 5.862 5.480 5.137
12.0
TC 6.296 6.240 6.183 6.127 6.043 5.967
SC 6.296 6.240 6.183 6.127 6.043 5.967
15.0
TC 6.734 6.674 6.613 6.553 6.463 6.382
SC 6.734 6.674 6.613 6.553 6.463 6.382
18.3
TC 7.215 7.151 7.087 7.022 6.926 6.839
###
SC 7.215 7.151 7.087 7.022 6.926 6.839
###
38
