McQuay MCK 020A

Panel ( Wireless Remote Control ) - MCK – A/AR
12
9
6
5
14
13
22
16
20
23
18
17
3
4
10
7
1
215
11
8
19
21
NO. PART DESCRIPTION NO. PART DESCRIPTION
1 FRONT PANEL 13 SWING MOTOR BRACKET
2 RECEIVER BRACKET 14 PANEL COVER
3 DISCHARGE HOUSING A 15 FIX PLATE
4 METAL LOUVER A 16 AIR INTAKE GRILLE
5 DISCHARGE HOUSING B 17 GRILLE LOCK
6 METAL LOUVER B 18 GRILLE LOCK BRACKET
7 DISCHARGE HOUSING D 19 IONIZER FILTER FRAME
8 LOUVER BRACKET 20 IONIZER FILTER
9 CRANK SHAFT 21 AIR FILTER
10 CRANK CONNECTOR 22 AIR SWING CAP
11 CRANK CROSS 23 REMOTE CONTROL
12 SWING MOTOR
91
