McQuay MCK 020A - Outdoor Unit Parts: MLC; M4 LC020; 025 B;BR & MLC030 B;BR

Panel - MCK – B/BR
NO PART DESCRIPTION NO. PART DESCRIPTION
1 FRAME 8 INTAKE GRILLE
2 RECEIVER BRACKET 9 GRILLE LOCK
3 LOUVER, SHORT 10 FILTER NET
4 LOUVER 11 RECEIVER COVER
5 LOUVER HOLDER 12 LED DISPLAY BOARD
6 LOUVER CLIP 13 LCD HANDSET
7 PLATE, FIX
94
